H07V-R 240mm² PVC Insulated Building Wire
Free
Single-core PVC insulated copper building wire for fixed wiring applications, rated 450/750V and tested according to IEC 60227-3.
Description
H07V-R 240mm² PVC insulated copper building wire for fixed wiring in conduits, trunking, panels, commercial, industrial, and large electrical installations.
Technical Specifications
| Type reference | 60227 IEC 01 / H07V-R |
|---|---|
| Nominal conductor size | 240mm² |
| Rated voltage | 450/750V |
| Number of cores | 1 |
| Conductor material | Copper |
| Conductor finish | Untinned |
| Number of conductor wires | 37 |
| Wire diameter | 2.95mm |
| Observed conductor resistance at 20°C | 0.0734 Ω/km |
| Insulation material | PVC/C compound |
| Specified insulation thickness | 2.2mm |
| Observed minimum insulation thickness | 2.02mm |
| Mean overall diameter | 23.9mm |
| Voltage test | 2500V for 5 minutes, no breakdown |
| Observed insulation resistance at 70°C | 0.0160 MΩ/km |
| Tested sample colour | Black |
| Reference standard | IEC 60227-3 |
| Price | Quote-based / available on request |
Final availability, colours, packaging, and project quantities are confirmed by quotation.
